Approvals:
UL Listed
|
|
Category:
ANSI/TIA-568-C.2 (Category 5e)
|
|
Meet:
47 CFR part 68
|
|
Wiring scheme:
T568A/T568B
|
|
Current Rating:
1.5 Amps
|
|
Insulation Resistance:
> 500 Mega-ohm
|
|
Contact Resistance:
< 20 milli-ohm
|
|
DC Resistance:
< 0.1 ohm max
|
|
Voltage:
< 150 VAC
|
|
Insertion Life:
750 Mating cycles
|
|
Pull Force:
20lbs (89N)
|
|
Temperature:
-40°C ~ 68°C
|
|
Humidity:
10% ~ 90% (RH)
|
|
IDC accept:
23AWG ~ 26AWG (Solid wire)
|
|
Cap:
Polycarbonate (PC resin), UL 94V-2 rated, Transparent Black
|
|
Housing:
Acrylonitrile Butadiene Styrene (ABS resin) + Polycarbonate (PC resin) UL94V-0 rated
|
|
Jack Contacts:
UL94V-0 rated
|
|
Contact Bracket:
Phosphor bronze flat wire, plated with 1.27um (50uin) thick hard gold on contact area over nickel underplate
|
|
PCB:
Polycarbonate (PC resin), UL94V-2 rated
|
|
IDC Terminals:
FR4, UL94V-0 rated
|
|
IDC Block:
Phosphor Bronze, plated with tin over nickel underplate Polycarbonate (PC resin) + Glass Fiber, UL94V-2 rated
|
